SSL Solid State Logic Super 9000

SuperAnalogue™ Technology

SuperAnalogue™ technology creates a signal path so transparent and wide bandwidth that nothing is lost, putting the engineer right there in the room with the artist. It's key design elements include a super-wide audio bandwidth, a ruler-flat frequency response, ultra-low transient intermodulation distortion, the absence of electrolytic capacitors in the audio path, extremely low noise and harmonic distortion, and exceptionally low phase shift across the audible spectrum. The result is unmatched punch, definition, and a larger-than-life sound stage—qualities that define the modern “SSL sound” and are why SuperAnalogue™ consoles remain the professional’s choice for music production.

Key Features

• Dual Mic Pre – Choose between SuperAnalogue™ (9000) & VHD™ (Duality) w/ +48V, Polarity invert, and Pad.
• 2 Impedance options for the mic pre: 1.3 kΩ and 11 kΩ. 
• Dedicated LINE Input with “Input Flip” to run through the Mic Pre
• Quintessential 9000/Duality Dynamics section:
  High-Performance THAT 2181A VCA compressor section.
  Peak/Hard Knee or Soft Knee modes.
  Program-Dependent or Fast Attack on/off.
  Logarithmic or Linear Release Modes.
• Classic Gate/Expander section.
  Fast Attack on/off.
  Hold control.
• 4-band SSL EQ with switchable modes. 
  Fully parametric mid-bands.
  Switchable between G-Series ‘Pink Knob’ 292 and E-Series ‘Black Knob’ 242 circuits.

• High and Low Pass filters. 
  18 dB per octave HPF & 12 dB per octave LPF.
• Balanced Insert point for connecting external devices into the signal path.
• Extensive ‘to sidechain’ functionality:
  Filters to Dynamics sidechain. 
  EQ to Dynamics sidechain.
• Flexible process-order routing:   
  Filters to input, Dynamics and Insert to output.
• Line Output Trim.
• Switchable input/output metering.
• External sidechain (key) input.
• Dynamics sidechain link – allows 2 x Super 9000’s compressors to work as a stereo pair (loudest signal wins). Linking via a TS/TRS jack cable (not included).
