Radial SGI (RX only)

Radial SGI - RX receiver only

Instrument Line Driver

The SGI is a high performance line driver system for guitars that takes an unbalanced instrument signal and allows you to drive it as far as 100 meters (300ft) without noise.

Features

• Balanced line driver for guitar and bass
• Send signal up to 100 meters (300ft) without loss
• Jensen transformers for optimal sound quality
• Delivers natural tone to off-stage amplifiers
• Can be powered by standard 9V pedalboard power supplies

The SGI sends guitar signals across long distances without signal loss or noise, while retaining the original tone of the instrument. In the studio, it allows the guitarist to sit in the control room and connect to a distant guitar amp. On stage, the SGI can be used to play the guitar amp using off-stage isolation cabinets or it can be used to manage guitar signals to and from wireless systems, pedalboards and amplifiers.

The SGI consists of two boxes: the SGI-TX transmitter and the SGI-RX receiver. The connection between the TX and RX is made using a standard balanced XLR microphone cable. To use, you simply plug your guitar into the SGI-TX input and connect your amp from the SGI-RX output and you are set to go. The SGI TX uses a discrete buffered circuit to drive your signals over long distances, while the SGI RX captures the signal and converts it to the appropriate impedance to feed your amplifier while retaining the original tone.

Radial Engineering - SGI Instrument Line Driver - SMART SHEET
